F2000 Tipper

The F2000 series heavy duty trucks, with over 30 years of reputation, perfect for even the most difficult tasks, bring unprecedented values to its users.

Experienced Engineering

Lightweight world advanced design concept, inheriting the company's military qualities and over 41 years of manufacturing experience. Built to meet even the toughest demands and setting the bar for safety and efficiency. This  series of vehicles utilizes Weichai engines, few leaf spring, lightweight high strength frame, rubber suspension and other advanced technologies. Utilizes WEVB engine exhaust breaking patented technology which increases breaking efficiency by more than 55%.

Product-Features

The F2000 series heavy duty trucks, with over 30 years of reputation, perfect for even the most difficult tasks, bring unprecedented values to its users.

1.Experienced Engineering

Lightweight world advanced design concept, inheriting the company’s military qualities and over 41 years of manufacturing experience. Built to meet even the toughest demands and setting the bar for safety and efficiency. This  series of vehicles utilizes Weichai engines, few leaf spring, lightweight high strength frame, rubber suspension and other advanced technologies. Utilizes WEVB engine exhaust breaking patented technology which increases breaking efficiency by more than 55%.

2.Superior Quality

Cabin utilizes high strength materials, left and right side doors are equipped with high strength anti collision beam, passed ECE-R29 crash test certification, lower floor to ensure the most driving room. Innovative use of lightweight high strength frame. Utilizes advanced Austria CRUISE software.

Specification

Trailer Truck Dump Truck
Drive type 4×2,  6×4、6×6 6×4、8×4
Cabin Lengthened high roof (N)
Lengthened flat roof (J)
Mid length flat roof (D)
Lengthened high roof (N)
Lengthened flat roof (J)
Mid length flat roof (D)
Engine WP10、WP12 Weichai power WP10, WP12
Emission Level Euro II, III, IV, V Euro II, III, IV, V
Transmission FAST F9, F10, F12 series Manual transmission 8F, 9F, 10F
Automatic transmission
Clutch ETONФ430 diaphragm imported or Chinese manufactured  ETONФ430 diaphragm imported or Chinese manufactured
Front Axle 7.5 ton MAN drum type
7.5 ton MAN plate type
6.5 ton Steyr
7.5 ton MAN drum type
6.5 ton STR double front axle
8 ton STR double front axle
6.5 ton STR
Rear Axle 13 ton Steyr double stage enhanced (drum)
13 ton MAN double stage punch welding (drum)
13 ton MAN single stage punch welding (drum)
16 ton STR double stage casting (drum)
16 ton MAN double stage casting (drum)
Suspension Multi leaf spring configuration Multi leaf spring configuration, 4 main piece + 2 U-bolts or 4 U-bolts
Frame(in mm) 780*243(8+5)、850*300(8+7) 850*300(8+7)
Fuel Tank 300 / 400 / 600 liter aluminum
380 liter steel
200 / 300 liter steel
300 / 400 liter aluminum
400 liter flat aluminum
Tires 12.00R20, 11.00R20, 12.00R22.5, 11.00R22.5 11.00R20、12.00R20
The fifth wheel Regular 90 saddle, enhanced 90 saddle, lightweight 90 saddle
Main specifications of SHACMAN F2000 6X4 Dump Truck
Reference picture



Model SX3255DR384
Driving Type 6×4
Wheelbase (mm) 3775+1400
Curb weight (kg) 12370
Gross weight (kg) 25000
Overall Dimension (mm) L 8495
W 2500
H 3450
Max. Speed (km/h) 78
Engine model WEICHAI WP10.340E32
Rate power 340HP
Emission Standard EURO II
Engine displacement(L) 9.726
Quantity of axle 3
Gearbox US Eaton Fuller technology, FAST,9JS135T-B, 9 forward gears, 1 reverse gear, with synchronizer
Tire 12.00R20
Fuel tank capacity(L) 400L, Aluminum
Cab German MAN technology, F2000 D Cabin, one sleeper,

hydraulic seat for driver, electric window glass lifter, with A/C, hydraulic cabin suspension

Front axle German MAN technology, HANDE,  MAN 7.5T front axle
Rear axle German MAN technology, HANDE, STR 16T rear axle, Hub Reduction, ratio 5.73
Fuel kind DIESEL
Other Equipment Manual cab tilting, Aluminum reservoir, 165Ah free-maintenance battery, desert air filter
Body Dump box,5600x2300x1500 mm, bottom 10mm side 8mm, HYVA 137 front lifting hydraulic cylinder
QUALITY 100PCT BRAND NEW. PRODUCED IN 2018
CIF,SHV port price(USD) 26,000-30,000
Road-type on-road
Max.weight ≤50T
Max.speed 70
Vehicle model SX3255PR404
Engine WP10.340E22
Emission standard EURO II
Displacement 9.762L
Rated output 250Kw
Clutch 430
Frame 850×300(8+7)
Front axle MAN7.5T
No.of axles 3
Axle distance 3975+1400
Rear axle 16T MAN double reduction 5.262
Tire 12.00R20
Suspension Multi leaf springs
Maximum design total mass 25000kg
Maximum design pay mass 12500kg
Fuel diesel
