Breaker

Hydraulic breaker is Shuishan series hydraulic hammer and is also the necessary equipment in mining, municipal engineering, demolition. They can be divided into triangles and right angles according to their shape.0TB hydraulic crushing hammer has the advantages of strong hitting force, good stability and low barrier rate. It is well received by users.

Product-Features

Hydraulic breaker is Shuishan series hydraulic hammer and is also the necessary equipment in mining, municipal engineering, demolition. They can be divided into triangles and right angles according to their shape.0TB hydraulic crushing hammer has the advantages of strong hitting force, good stability and low barrier rate. It is well received by users.

Specification

Model OTB140 OTB140A OTB1800 OTB155
Total weight Triangular 1740 1760 2144 2413
Tower 1754 1773 1972 2555
Overall length Triangular 2414 2414 2603 2776
Tower
Full width Triangular 2823 2823 3047 3119
508 508 600 610
Tower 620 620 620 710
Working pressure 160- 180 160- 180 160- 180 160- 180
Driving flow 120~ 180 120- 180 150- 210 180- 240
Impact Rate 350- 500 350~ 500 300- 450 300- 450
Hose diameter 1 1 1 1 1/4
Rod diameter 140 140 150 155
Rod weight 126 126 155 182
Matching capacity 07-0.9 0.7-0.9 0.9-1.2 1.1-1.4
Weight of the euqipment 18-26 18-26 25-30 28- 45
